Basic Fixed VOC Detector

... but still equipped with high performance,
    extended long-life PID sensor


Model PIDScan 600

PIDScan 600 is a new generation PID gas detector that adopts built-in pump sampling and unique ceramic-glass PID lamp with integrated built-in temperature, and humidity sensor signal compensation process assembly, which effectively reduces the interference of humidity on
the instrument and brings users better experience of high stability and long service life.




Most basic fixed PID detector

to ensure affordability and competitivness, and yet is equipped with high performance ceramic PID lamp

Built-in diahragm pump

to ensure reliable, improved life and operation performance of the PID lamp

Unique ceramic-glass PID sensor

has proven to yield stable performance and long-sensor life beyond expectations

Built-in temperature and humidity sensors

to ensure accurate and real-time compensation measurements under all weather conditions

  • 4-20 mA analog and MODBUS RS485 output ; HART as optional.

  • PID sensor highly resistance to humidity interference

  • Explosion proof EEx d IIC T6 for hazardous application

  • With built-in diaphragm pump to draw in sample gas

  • Magnetic interface for non-intrusive access to menu

  • Large numerical and graphical dot-matrix display with backlight sensor



PID sensor                              10.6 eV

Range / Resolution  /                0 - 2000 ppm / 1 ppm (high range version)

(optional range)                       0.0 - 100.0 ppm / 0.1 ppm (standard version) /  (0.0 - 1000 ppm)

                                                 0.00 - 10.00 ppm / 0.01 ppm ( ultra sensitive version ) / ( 0.00 - 20 ppm)

                                                 *  with Temperature and Humidity compensation on board

Pump                                        Built-in diaphragm pump

Relay contacts                         SPST dry contacts (x3)

Ring LEDs Alarm                     Built-in ring alarm LEDs; Yellow and Red

Response Time                       T90 < 10 sec (improved)

EX Approval                            ATEX II 2G Ex d IIC T6  Gb

                                                UL Class I Div I Group B, C and D

IP Rating                                 IP66 EMI / RFI

Compliance to EMI / RFI         Directive 89 / 336 / EEC

Power                                     9 - 36 Vdc, max. 125 mA at 24 Vdc

Cable                                     3-wire shielded; max. 1 kOhm at 24 Vdc

Output  / (option)                   4 - 20 mA , HART (option)

                                               Modbus RS 485

                                               SPST relay contacts (x2), Fault relay (x1); max. 30 V, 2 A.

Sampling method                  Built-in diaphragm pump (~500 ml / min)

Display                                  Graphic LCD 128 x 64 pixels, with backlit

User interface                       Non-intrusive using magnetic key

Operating Cond.                  Temperature: -20 degC to +60 degC (-4 degF to 140 degF)                                                                      Humidity: 0 - 95%RH (non-condensing)

Physical Data                        Weight: 3.5 Kg

                                              Dimension: L 124 x D 125 x H 198 (mm)
